' {$STAMP BS2}
' {$PBASIC 2.5}
' final-bo-bot-code.bs2
DEBUG "Programming Running!"
irDetectLEft VAR Bit
irDetectRight VAR Bit
pulseLEft VAR Word
pulseRight VAR Word
pulseCount VAR Byte
FREQOUT 4, 2000, 3000
DO
FREQOUT 8, 1, 38500
irDetectLeft = IN9
FREQOUT 2, 1, 38500
irDetectRight = IN0
IF (irDetectLeft = 0) AND (irDetectRight = 0) THEN
FOR pulseCount = 0 TO 15
PULSOUT 13, 650
PULSOUT 12, 850
GOSUB turn_right
PAUSE 50
NEXT
ELSEIF (irDetectLeft = 0) THEN
pulseLeft = 850
pulseRight = 850
PAUSE 50
ELSEIF (irDetectRight = 0) THEN
pulseLeft = 650
pulseRight = 650
PAUSE 50
ELSE
pulseLeft = 850
pulseRight = 650
ENDIF
IF (irDetectLeft = 0) THEN
HIGH 10
PAUSE 10
ELSEIF (irDetectRight = 0) THEN
HIGH 1
PAUSE 10
ELSEIF (irDetectRight = 0) AND (irDetectLeft = 0) THEN
HIGH 10
HIGH 1
PAUSE 1000
ELSE
LOW 10
LOW 1
ENDIF
PULSOUT 13, pulseLeft
PULSOUT 12, pulseRight
PAUSE 15
LOOP
'----Subroutines
forward_pulse:
PULSOUT 13, 850
PULSOUT 12, 650
PAUSE 20
RETURN
turn_left:
FOR pulseCount = 0 TO 20
PULSOUT 13, 650
PULSOUT 12, 650
PAUSE 20
NEXT
RETURN
turn_right:
FOR pulseCount = 0 TO 20
PULSOUT 13, 850
PULSOUT 12, 850
PAUSE 20
NEXT
RETURN
back_up:
FOR pulseCount = 0 TO 40
PULSOUT 13, 650
PULSOUT 12, 850
PAUSE 20
NEXT
RETURN
